XL11

2.4mm Connector Straight Plug (m) .086" Cable Solder-Clamp

Electrical
Impedance	50 Ohms
Frequency	50 GHz
VSWR	1.15:1

Mechanical
Mating Torque	9
Weight	0.009

Piece Part	Material
Body	Passivated Stainless Steel
Contact	Gold-plated Beryllium Copper
Insulator	ULTEM® (Polyetherimide)
Gasket	Silicone Rubber
Coupling Nut	Passivated Stainless Steel
Rear Body	Passivated Stainless Steel
Snap Ring	Beryllium Copper
