NM20
N Right-angle Plug (m) .141 Cable
| Electrical | |
|---|---|
| Impedance | 50 Ohms |
| Frequency | 12 GHz |
| VSWR | 1.23:1 |
| Insertion Loss | 0.10392 |
| Mechanical | |
|---|---|
| Mating Torque | 15 In Lbs |
| Weight | 0.079 |
| Piece Part | Material |
|---|---|
| Contact | Gold-plated Brass |
| Insulator | PTFE (Polytetrafluoroethylene) |
| Rear Body | Gold-plated Brass |
| Front Body | Passivated Stainless Steel |
| Front Body | Passivated Stainless Steel |
| Coupling Nut | Passivated Stainless Steel |
| Snap Ring | Beryllium Copper |
