KO10
2.92mm Straight Plug (m) .047 Cable
/KO10.png)
| Electrical | |
|---|---|
| Impedance | 50 Ohms |
| Frequency | 40 GHz |
| VSWR | 1.44:1 |
| Mechanical | |
|---|---|
| Mating Torque | 8 |
| Weight | 0.005 |
| Piece Part | Material |
|---|---|
| Contact | Gold-plated Beryllium Copper |
| Insulator | ULTEM® (Polyetherimide) |
| Gasket | Silicone Rubber |
| Coupling Nut | Passivated Stainless Steel |
| Snap Ring | Beryllium Copper |
